Power
Many forklifts are made to operate on propane gas. Forklifts which utilize propane are very easy to refill. The gas is stored in a pressurized tank on the rear of the truck. The propane is pushed into the engine, where it is converted into vapor and then the vapor combines with air. The forklift throttle is utilized to be able to control the flow of vapor. A spark plug ignites the air and vapor mixture producing pressure which makes the pistons move. The pistons turn the wheels and run the hydraulic pump.
Propane powered forklifts are suggested for use within warehouses and other buildings since they are clean burning with low emissions.
Hydraulics
What allows a forklift to raise and move heavy things from one place to another is the hydraulic system. Cylinders, a pump and tubes make up the hydraulic system. The pump forces dense fluid in the tubing and into the cylinders. The build up of pressure pushes a piston, which lifts the forks. When the operator lowers the forks, the hydraulic fluid flows out of the cylinders and back in the pump.
Steering
Propane forklifts work well where maneuverability is needed. Unlike an automobile, a forklift utilizes its rear wheels to pivot, which allows the forklift to turn fast on a tight radius.
Click to Download the pdf
Forklift Parts
Yale
Powertrain
Lift trucks should be really tough to last for hours of operation in many extreme settings. While being ergonomic for operators, these machines have to be able to move loads efficiently and fast. The reliable, rugged Yale powertrain offers superior durability through its state of the art clutch packs, computer managed transmission and engine and extremely robust gears and...
More
Crown
Crown makes many models of electric rider pallet trucks for a wide variety of uses. When it comes to high-speed transporting, dock work or low-level order picking, rider pallet trucks are truly the ideal option.
Regardless of the type, the main lift truck operator productivity preferences are addressed. Whether it is the center controlled PC Pallet Truck Series, the End...
More
Nissan
Counterbalance lift trucks are essentially forklifts that are designed with counterweight at the back of the machine. The counterweight works to balance the weight which the tines are carrying at the front of the cargo. This design is engineered to stabilize traditional forklifts. When it comes to electric counterbalance forklifts, the counterweight is formed by the battery itself.
Practically every...
More
Doosan
Size
On the rear of the forklift is a counterbalance, which enables the lift truck to lift really heavy objects. The counterbalance provides balance so that the machinery would not tip over while lifting and transporting heavy loads. Forklifts are rated based on their load capacity. A small forklift that could raise 1800 kilograms weighs about 4000 kilograms, that is...
More
Toyota
For lift trucks these days, there are numerous attachment options offered. Nearly all attachments are made to be used on standard forklifts and are made to be utilized on VNA and reach trucks. It is essential to note that OSHA needs approval for any attachment that should be approved for use by the particular lift truck manufacturer.
The sideshift attachment...
More
Hyster
Lower Operating Expenses by Protecting Your Investment
Abuse of the lift truck is preventable, therefore Hyster forklifts has a total solution to help eliminate this kind of abuse. The dealers have a variety of cost effective options and simple solutions to take into consideration in an effort to avoid lift truck abuse from occurring.
Product or Service Solutions, Worn Tires,...
More
Komatsu
Does Cold Temperature Really Affect the Level Gauge on a Propane Tank?
Propane is similar to nearly all other kinds of materials in that it is affected by cold temperatures. The propane gas contracts when the temperature declines. That reduced level of gas inside the tank is reflected by the gauge that reflects the tank level. Normally, this happens whenever...
